MSI B450M Pro-VDH

Descripción
Supports AMD® RYZEN? 1st and 2nd Generation / Ryzen? with Radeon? Vega Graphics Processors for Socket AM4
Supports DDR4-3466+(OC) Memory
Audio Boost: Reward your ears with studio grade sound quality.
DDR4 Boost: Fully isolated, shielded and optimized DDR4 PCB design to give your DDR4 memory a performance boost.
Turbo M.2: Delivering Speeds Up to 32Gb/s.
EZ Debug LED: Easiest way to troubleshoot.
PCI-E Steel Armor: Protecting VGA cards against bending for better performance, stability and strength.
X-Boost: Software that auto-detects and allows you to boost the performance of any storage or USB device.
Core Boost: With premium layout and fully digital power design to support more cores and provide better performance.

Especificaciones
SOCKET: AM4
CPU (MAX SUPPORT): Ryzen 7
CHIPSET: AMD® B450 Chipset
DDR4 MEMORY
- 1866/ 2133/ 2400/ 2667Mhz (by JEDEC)
- 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 MHz (by A-XMP OC MODE)
MEMORY CHANNEL: Dual
DIMM SLOTS: 4
MAX MEMORY (GB): 64
PCI-E X16: 1
PCI-E GEN: Gen3
PCI-E X1: 2
SATAIII: 4
M.2 SLOT: 1
RAID: 0/1/10
TPM (HEADER): 1
LAN: 1(Realtek® 8111H)
USB 3.1 PORTS (FRONT): 2(Gen1)
USB 3.1 PORTS (REAR): 4(Gen1) Type A
USB 2.0 PORTS (FRONT): 4
USB 2.0 PORTS (REAR): 4
SERIAL PORTS(FRONT): 1
AUDIO PORTS (REAR): 3(Realtek® ALC892 Codec)
DVI-D: 1
VGA: 1
HDMI: 1
DIRECTX: 12
FORM FACTOR: M-ATX
OPERATING SYSTEM
- Support for Windows® 10 64-bit
- Support for Windows® 7 64-bit
- * To support Windows® 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU.
