Fuente de Alimentacion XFX P1-500B-XTFR 500W 80+ Bronze

Descripción
EasyRail? Plus Technology allowing plenty of wattage headroom to handle your devices
Ultra Quiet Fan Design
AMD Radeon CrossFire Ready
NVIDIA GeForce SLI Ready
Multiple PCI-E 6-Pin and 6+2Pin connectors
True Wattage guarantee
80 Plus Bronze certifying 85% power efficiency
Extreme heat tested capacitors

Especificaciones
GENERAL
+12V Rail Outputs : Single
100% Tested and Verified : Y
ATX12V 2.2 & ESP12V 2.91 Compliant : Y
ATX12V 2.31 Compliant : Y
Compatible with Intel and AMD platforms : Y

TECHNOLOGIES
CrossFire Ready : Y
SLI Ready : Y

RATINGS & EFFICIENCY
AC Input Current (Arms) : 8-5 Amps (rms)
AC Input Frequency (Hz) : 50/60 Hz
AC Input Voltage (Vac) : 100-240 VAC
Efficiency @ Typical Load : Up to 85%
Energy-Efficiency : 80 Plus Bronze Certified
Maximum Wattage : 500 Watts

OTHER FEATURES
Tight voltage regulation (±5%) : Y

LOAD RANGE
Max -12V Output Current (A) : 0.3A
Max +12V Output Current (A) : 38A (up to 465W, 93% of 500W)
Max +3.3V Output Current (A) : 20A (combined +3.3V & +5V up to 102W)
Max +5V Output Current (A) : 15A (combined +3.3V & +5V up to 102W)
Max +5VSB Output Current (A) : 2.5A

CABLE CONNECTORS
Fixed FDD : One Connector 10cm
Fixed (Molex): 2, 1x Fixed Flat cable (40+10cm)
Fixed PCI-E Connectors : 2, 1x Fixed Flat cable  (6+2)pin+(6+2)pin (55+10cm)
Fixed ATX12V / EPS12V : 2, 2x Fixed Flat cable (4+4)pin (55cm)
Fixed Motherboard Connector : 1x sleeved (20+4)pin (50cm)
Fixed SATA : 6, 2x Fixed Flat Cable (45+15+15cm)

SAFETY & PROTECTION
Active Power Factor Correction (PFC) : Y
Over Current Protection (OCP) : Y
Over Power Protection (OPP) : Y
Over Voltage Protection (OVP) : Y
Short Circuit Protection (SCP) : Y
Under Voltage Protection (UVP) : Y

PHYSICAL
Cooling Fan Size (mm) : 120mm Sleeve Fan (2000rpm, 74.48CFM, 29.28dBA)
Master Carton Dimensions (mm) : 550x370x275
Master Carton Dimensions (inch) : 21.65x14.5x10.83
Master Carton Weight (Kg) : 20.66
Master Carton Weight (lb) : 45.55
Package Dimensions (mm) : 255x175x105
Package Dimensions (inch) : 10x6.8x4.13
Package Weight (Kg) : 2.066
Package Weight (lb) : 4.555
Product Dimension LxWxH (mm) : 140x150x86
Product Dimension LxWxH (inch) : 5.5x5.9x3.38
Product Net Weight (kg) : 1.488
Product Net Weight (lb) : 3.28

INCLUDES
AC Power Cord : 1
Units/Carton : 10
Users Manual : 1
